PVC Tubing Features & Benefits

Click image to enlarge

Freelin-Wade's flexible PVC uses a non-DEHP, non-phthalate plasticizer. We pioneered the use of this bio-based and socially conscious material in the plastic tubing industry years ago.

Our PVC has a smooth interior and exterior which prevents sediment accumulation, making it well-suited for the food & beverage, medical and pharmaceutical industries. Contact Us for more information.

Characteristics of Polyvinyl Chloride

  • Crystal clear for easy visualization of fluid flow.
  • Non-standard colors also available.
  • Custom sizes available
  • from .090” to 3/4” OD.
  • REACH, RoHS, Cal Prop 65 compliant.
  • Materials certificates available showing full traceability.
  • Gamma & EtO sterilizable.
  • Chemical resistant.
  • Manufactured in an ISO-compliant facility in the USA.
  • Non-oxidizing and non-contaminating
  • Smooth, polished inner wall.
  • Easily slips over barbed fittings and grips
    securely.
  • Contains no phthalates, latex or BPA.
  • Economical alternative to overengineered solutions.
  • Agency compliances: FDA for Food Contact, meets USPVI testing requirements.
  • Compatible with most oils, fuels, gases, and low-grade acids. Call for
    application-specific compatibility.
65A 70A 80A
Specifications
Hardness - 65 Shore A
  • 15 Sec. Delay +/-3
  • ASTM D-2240
Temperature Range
  • -30°F to +150°F
Specific Gravity - 1.22
  • +/-0.02
  • ASTM D-792
Tensile Strength - 1900 psi
  • ASTM D-638
Elongation - 415%
  • ASTM D-638
Suggested Fitting
  • Barb
Specifications
Hardness - 70 Shore A
  • 15 Sec. Delay +/-3
  • ASTM D-2240
Temperature Range
  • -30°F to +150°F
Specific Gravity - 1.22
  • +/-0.02
  • ASTM D-792
Tensile Strength - 2250 psi
  • ASTM D-638
Ultimate Elongation - 425%
  • ASTM D-638
Suggested Fitting
  • Barb
Specifications
Hardness - 80 Shore A
  • 15 Sec. Delay +/-3
  • ASTM D-2240
Temperature Range
  • -30°F to +150°F
Specific Gravity - 1.22
  • +/-0.02
  • ASTM D-792
Tensile Strength - 2750 psi
  • ASTM D-638
Ultimate Elongation - 350%
  • ASTM D-638
Suggested Fitting
  • Barb

This information has been gathered from standard reference materials and/or test data that are believed to be accurate and reliable. Nothing herein shall be deemed to be a warranty or representation, express or implied, with respect to the use of such information or the use of the goods described for any particular purpose alone or in combination with other goods and/or processes. It is offered solely for your consideration, investigation and verification.

Applications for Flexible PVC Tubing

  • Non-invasive Medical
  • Dental
  • Veterinarian
  • General Laboratory
  • Food & Beverage
  • Biopharmaceutical
  • Aerospace
  • Ink Printers

PVC Pipe Custom Options

Additional custom sizes are also available for 65 Shore A , 70 Shore A and 80 Shore A PVC. To find out pricing and lead times, please contact our customer service team today. We will do everything we can to say YES to your specific tubing needs.

65A Non-Phthalate Polyvinyl Chloride: PVC
Part Number &
Color Code
Packaging
Unit Size
OD ID Wall Standard Color Working Pressure
75°F/25°C
Working Pressure
150°F/65°C
lbs./ 100' Bend Radius Fitting

1J-721-10

1A-721-10

100' Bag

2500' Reel

1/8" 1/16" .031" Clear Color 85 PSI 10 PSI .51 1/4" B

1J-722-10

1A-722-10

100' Bag

1000' Reel

1/4" 1/8" .062" Clear Color 70 PSI 10 PSI 2 3/8" B

1J-723-10

1A-723-10

100' Bag

500' Reel

5/16" 3/16" .062" Clear Color 50 PSI 5 PSI 2.6 5/8" B
Variations Available: Colors • Cutting • Bonding• Printing • Packaging • Sizes



80A Non-Phthalate Polyvinyl Chloride: PVC
Part Number &
Color Code
Packaging
Unit Size
OD ID Wall Standard Color Working Pressure
75°F/25°C
Working Pressure
150°F/65°C
lbs./ 100' Bend Radius Fitting

1J-700-10

1A-700-10

100' Bag

2500' Reel

1/8" 1/16" .031" Clear Color 145 PSI 20 PSI .51 3/8" B

1J-701-10

1A-701-10

100' Bag

1000' Reel

1/4" 1/8" .062" Clear Color 165 PSI 25 PSI 2 1/2" B

1J-702-10

1A-702-10

100' Bag

1000' Reel

1/4" 0.17" 0.04 Clear Color 95 PSI 10 PSI 1.75 1" B

1J-703-10

1A-703-10

100' Bag

10 500' Reel

5/16" 3/16" .062" Clear Color 110 PSI 15 PSI 2.6 5/8" B

1J-704-10

1A-704-10

100' Bag

500' Reel

3/8" 1/4" .062" Clear Color 91 PSI 15 PSI 3.25 7/8" B

1J-705-10

1A-705-10

100' Bag

200' Reel

1/2" 3/8" .062" Clear Color 57 PSI 10 PSI 4.55 1-3/4" B

1A-706-10

100' Reel 3/4" 1/2" .125" Clear Color 63 PSI 15 PSI 13.01 1-1/4" B
Variations Available: Colors • Cutting • Bonding• Printing • Packaging • Sizes



Contact Freelin-Wade to Learn More

Free samples of stock tubing are available through our website. Contact us today!

Flexible PVC Colors Standard tubing color is available in Clear Color clear. Our Non-Reinforced PVC tubing products are also available in these colors. Please allow three weeks to fulfill your order.

Color Assortment Options
